RFQ
01Part-number led inquiry path
MCP1600-E003E26 can be used as the direct starting point for quotation, BOM sharing and availability discussion.
Cables & interconnects• MCP1600-E003E26
NVIDIA Mellanox MCP1600-E003E26 100Gb/s QSFP28 Passive Direct Attach Copper Cable – 3m, EDR InfiniBand, Low Latency, Near-Zero Power for Data Center Interconnects
200Gb/s Mellanox MCP1600-E003E26 passive copper DAC cable for HDR InfiniBand. 3m length, low latency, <0.1W power, LSZH jacket. Ideal for HPC and data centers.
RFQ
Inquiry ready
Clear path for part number, quantity and BOM-led contact.
EN / AR
Bilingual buyer flow
Useful for procurement teams coordinating technical review across regions.
Datasheet available
The product datasheet can be downloaded directly from this page.
Fast technical snapshotDatasheet available
MCP1600-E003E26
Product photoCMS image ready
Selected specs
3 meters ( ± 0.050m tolerance )
Max 0.1W
Deployment fit
Top-of-Rack (ToR) switching: Connect InfiniBand HDR switches to compute nodes within the same rack.
Follow-up path
Quote / Compatibility / Availability
Prepared for part-number led and BOM-led requests
MCP1600-E003E26
Product photoCMS image ready
Product media
From product visual to RFQ context
When product photography is available it appears here for faster review, and a clean technical outline remains useful for early evaluation when imagery is limited.
01Product imagery when available
02Clear technical outline for fast review
03Built for specification review before inquiry
Overview
Product overview
The Mellanox MCP1600-E003E26 is a high-performance passive copper cable designed for 200Gb/s InfiniBand HDR (High Data Rate) applications. Part of the LinkX series, this QSFP56 direct attach cable integrates eight high-speed copper pairs operating at 50Gb/s PAM4 modulation per lane, delivering aggregate bandwidth of 200Gb/s. The assembly includes an EEPROM with product configuration data accessible via SFF-8636 I²C management interface. With 0.1W typical power consumption and passive design, it significantly reduces data center power and cooling costs compared to active optical cables or transceiver modules. Ideal for short-reach interconnects (up to 3 meters), the cable supports hot-pluggable installation and meets rigorous IBTA InfiniBand HDR compliance.
Key features
- Up to 200Gb/s aggregate data rate (4x 50Gb/s PAM4): Fully compliant with IBTA InfiniBand HDR specification
- Passive copper design – no active components, zero latency penalty: Hot-pluggable QSFP56 form factor per SFF-8665
- Low power consumption: < 0.1W (max) from single 3.3V supply: EEPROM with product identification and serialization (I²C interface)
- Robust cable construction: 26 AWG conductors, LSZH outer jacket: Operating case temperature range: 0°C to 70°C
- Superior BER performance: < 1E-15 with Mellanox InfiniBand HDR systems: RoHS compliant, Lead-Free (LF) and Halogen-Free (HF) PCB
- The MCP1600-E003E26 leverages 4-lane PAM4 modulation at 50Gb/s per lane, enabling 200Gb/s throughput over passive copper infrastructure. It adheres to SFF-8665 mechanical requirements and SFF-8636 management interface. Each cable undergoes stringent production testing including high-speed eye diagram validation, insertion loss, and crosstalk screening to guarantee out-of-the-box reliability. The 26 AWG gauge ensures optimal signal integrity at 3-meter distance while maintaining minimum bend radius: single bend 47mm, assembly/repeated bend 94mm, facilitating flexible deployment in high-density racks.
Typical applications
- Top-of-Rack (ToR) switching: Connect InfiniBand HDR switches to compute nodes within the same rack.
- High-Performance Computing (HPC): Short-reach links between GPU servers and leaf switches in clustered environments.
- Data Center Interconnects: Cost-effective point-to-point connections for storage nodes and management networks.
- AI/ML Clusters: Ultra-low latency links essential for distributed training workloads.
Buying flow
How this product review turns into a real inquiry
This section gives buyers a practical handoff from technical review into quotation or compatibility follow-up.
01
Identify the exact target model
Start from MCP1600-E003E26 or the product name to reduce ambiguity before quotation starts.
02
Add quantity or deployment context
Share quantity, destination or BOM context so the commercial follow-up is aligned with the project scope.
03
Move into availability and fit review
Use the page as the handoff point for stock discussion, compatibility checks and delivery planning.
Technical snapshot
- 3 meters ( ± 0.050m tolerance )
- Max 0.1W
Trust signals
Why buyers use this page to review MCP1600-E003E26
The page is designed to reduce the distance between specification review and a real commercial inquiry.
Review
02Compatibility review before follow-up
The NVIDIA Mellanox MCP1600-E003E26 100Gb/s QSFP28 Passive Direct Attach Copper Cable – 3m, EDR InfiniBand, Low Latency, Near-Zero Power for Data Center Interconnects page is positioned to support compatibility questions and project-fit review before commercial action is finalized.
Project
03Project and quantity alignment
This model can be framed against use cases such as Top-of-Rack (ToR) switching: Connect InfiniBand HDR switches to compute nodes within the same rack. together with quantity and rollout timing.
Language
04English and Arabic follow-up
The bilingual route supports regional buying teams that need technical review and RFQ handling in two languages.
FAQ
Frequently asked questions about MCP1600-E003E26
Short answers that give buyers clearer expectations before they move into the quote form.
Can I request a quote for MCP1600-E003E26 directly from this page?01
Yes. This page is designed to move MCP1600-E003E26 review directly into quotation, availability or BOM discussion.
Does MCP1600-E003E26 support compatibility discussion before purchase?02
Yes. The page can be used to frame compatibility questions around Top-of-Rack (ToR) switching: Connect InfiniBand HDR switches to compute nodes within the same rack. before commercial follow-up.
Can MCP1600-E003E26 be compared with nearby models in the same family?03
Yes. Related products within the same category give buyers an internal comparison path before they submit an inquiry.
Can I send quantity or a BOM list with the inquiry?04
Yes. The inquiry path is designed to accept part numbers, quantity, BOM context and availability requirements in one submission.
