NVIDIA Mellanox MFS1S00-H020V 200Gb/s QSFP56 Active Optical Cable – 20m MMF AOC for InfiniBand HDR & 200GbE
200Gb/s QSFP56 active optical cable for InfiniBand HDR & 200GbE. 20m reach, 5.0W power, PAM4 modulation. Ideal for HPC & data centers.
RFQ
Inquiry ready
Clear path for part number, quantity and BOM-led contact.
EN / AR
Bilingual buyer flow
Useful for procurement teams coordinating technical review across regions.
Datasheet available
The product datasheet can be downloaded directly from this page.
Fast technical snapshotDatasheet available
MFS1S00-H020V
Product photoCMS image ready
Selected specs
Power Dissipation (each end, retiming on all lanes)
1 Internal temperature readout through DDM up to 75°C is allowed. Absolute maximum ratings: Vcc -0.3 to 3.6V; data input voltage -0.3 to 3.465V; damage threshold 3.4 dBm.
Deployment fit
High Performance Computing (HPC) clusters using InfiniBand HDR fabrics (20m cross-rack links)
Follow-up path
Quote / Compatibility / Availability
Prepared for part-number led and BOM-led requests
MFS1S00-H020V
Product photoCMS image ready
Product media
From product visual to RFQ context
When product photography is available it appears here for faster review, and a clean technical outline remains useful for early evaluation when imagery is limited.
01Product imagery when available
02Clear technical outline for fast review
03Built for specification review before inquiry
Overview
Product overview
The NVIDIA Mellanox MFS1S00-H020V is a high-performance 200Gb/s QSFP56 Multi-Mode Fiber (MMF) active optical cable, delivering 20 meters of reliable connectivity for next-generation data centers and high-performance computing clusters. Designed for InfiniBand HDR (High Data Rate) and 200 Gigabit Ethernet environments, this AOC leverages 50Gb/s PAM4 modulation per lane (4x50G) to achieve aggregate 200Gb/s bandwidth. Compared to passive DACs, which are typically limited to 3-5 meters at 200G, the MFS1S00-H020V enables superior signal integrity over extended distances, tighter bend radii, reduced weight, and improved airflow, while consuming only 5.0W typical per end (with retiming enabled). Built with VCSEL arrays and integrated retiming circuitry, it provides bit error rates better than 1E-15 and predictable low latency. Fully compliant with SFF-8665 (QSFP56) and SFF-8636 management interface, the cable is hot pluggable and RoHS compliant.
Key features
- For TX & RX up to 50Gb/s rates / Programmable signal conditioning: Rx output amplitude, pre-emphasis; Tx input equalizer
- Standard port, single 3.3V power supply / Digital Diagnostic Monitoring (DDM): Real-time optical power, temperature, voltage monitoring
- The MFS1S00-H020V employs VCSEL-based active optics with four multi-mode fiber strands per end, each lane operating at 50Gb/s PAM4 (53.125 GBd) to achieve 200Gb/s aggregate bandwidth. The cable integrates programmable input equalizers and output pre-emphasis, enabling fine-tuning for various host systems to maximize link margin over the 20-meter distance. Retiming can be selectively enabled per lane, reducing jitter at high data rates while maintaining backward compatibility with lower speeds (e.g., 100Gb/s NRZ) when retiming is disabled. The LSZH (Low Smoke Zero Halogen) jacket enhances fire safety in dense deployments. All active electronics are hermetically sealed inside the QSFP56 connector housings, requiring no external power beyond standard 3.3V from the host port. The cable supports rate select via SFF-8636 registers, allowing configuration for 25.78125 GBd NRZ (EDR) or 26.56250 GBd PAM4 (HDR) operation.
Typical applications
- High Performance Computing (HPC) clusters using InfiniBand HDR fabrics (20m cross-rack links)
- 200GbE data center leaf-spine architectures connecting top-of-rack switches to middle-of-row switches
- Storage networks with NVMe-oF over InfiniBand requiring high bandwidth and low latency across multiple racks
- AI/ML training clusters leveraging NVIDIA Quantum-2 switches across adjacent racks
- Switch-to-server connections beyond 10 meters, up to 20 meters: Hyperscale data center deployments requiring high-density, power-efficient cabling over moderate distances
Buying flow
How this product review turns into a real inquiry
This section gives buyers a practical handoff from technical review into quotation or compatibility follow-up.
01
Identify the exact target model
Start from MFS1S00-H020V or the product name to reduce ambiguity before quotation starts.
02
Add quantity or deployment context
Share quantity, destination or BOM context so the commercial follow-up is aligned with the project scope.
03
Move into availability and fit review
Use the page as the handoff point for stock discussion, compatibility checks and delivery planning.
Technical snapshot
- Power Dissipation (each end, retiming on all lanes)
- 1 Internal temperature readout through DDM up to 75°C is allowed. Absolute maximum ratings: Vcc -0.3 to 3.6V; data input voltage -0.3 to 3.465V; damage threshold 3.4 dBm.
Trust signals
Why buyers use this page to review MFS1S00-H020V
The page is designed to reduce the distance between specification review and a real commercial inquiry.
Review
02Compatibility review before follow-up
The NVIDIA Mellanox MFS1S00-H020V 200Gb/s QSFP56 Active Optical Cable – 20m MMF AOC for InfiniBand HDR & 200GbE page is positioned to support compatibility questions and project-fit review before commercial action is finalized.
Project
03Project and quantity alignment
This model can be framed against use cases such as High Performance Computing (HPC) clusters using InfiniBand HDR fabrics (20m cross-rack links) together with quantity and rollout timing.
Language
04English and Arabic follow-up
The bilingual route supports regional buying teams that need technical review and RFQ handling in two languages.
FAQ
Frequently asked questions about MFS1S00-H020V
Short answers that give buyers clearer expectations before they move into the quote form.
Can I request a quote for MFS1S00-H020V directly from this page?01
Yes. This page is designed to move MFS1S00-H020V review directly into quotation, availability or BOM discussion.
Does MFS1S00-H020V support compatibility discussion before purchase?02
Yes. The page can be used to frame compatibility questions around High Performance Computing (HPC) clusters using InfiniBand HDR fabrics (20m cross-rack links) before commercial follow-up.
Can MFS1S00-H020V be compared with nearby models in the same family?03
Yes. Related products within the same category give buyers an internal comparison path before they submit an inquiry.
Can I send quantity or a BOM list with the inquiry?04
Yes. The inquiry path is designed to accept part numbers, quantity, BOM context and availability requirements in one submission.
