NVIDIA MFP7E20-N015 1:2 Splitter Cable | 800G to 2x400G MPO-12/APC OM4, 15m
NVIDIA MFP7E20-N015 1:2 splitter cable converts 800G OSFP to dual 400G links. MPO-12/APC connectors, OM4 fiber, 15m length. Ideal for AI clusters & data centers.
RFQ
Inquiry ready
Clear path for part number, quantity and BOM-led contact.
EN / AR
Bilingual buyer flow
Useful for procurement teams coordinating technical review across regions.
Datasheet available
The product datasheet can be downloaded directly from this page.
Fast technical snapshotDatasheet available
MFP7E20-N015
Product photoCMS image ready
Selected specs
50/125μm Multimode OM4 (for lengths >30m; 15m uses OM4)
8 fibers (4 transmit / 4 receive per branch mapping)
15 meters (tolerance: +2% x L / -0)
≤0.35 dB + 0.0004 x L (L=15m → ≤0.356 dB per connector end face)
Deployment fit
Connecting NVIDIA twin‑port OSFP 800G transceivers (e.g., MMA4Z00‑NS) in top‑of‑rack switches to ConnectX‑7 or BlueField‑3 DPU adapters using 400G OSFP/QSFP112 modules.
Follow-up path
Quote / Compatibility / Availability
Prepared for part-number led and BOM-led requests
MFP7E20-N015
Product photoCMS image ready
Product media
From product visual to RFQ context
When product photography is available it appears here for faster review, and a clean technical outline remains useful for early evaluation when imagery is limited.
01Product imagery when available
02Clear technical outline for fast review
03Built for specification review before inquiry
Overview
Product overview
The NVIDIA MFP7E20-Nxxx series provides a unique 4‑channel‑to‑two‑2‑channel splitting function within a single MPO-12/APC to dual MPO-12/APC assembly. The MFP7E20-N015 offers 15 meters of reach using low-loss OM4 multimode fiber with aqua LSZH jacket. The angled physical contact (APC) polish (8‑degree) eliminates back reflections and maintains superior optical return loss ≥35 dB. This breakout cable enables one 800G port (twin OSFP) to fan out into two independent 200G/400G links, maximizing port density and reducing switch‑to‑adapter cabling complexity. Each cable is rigorously factory‑tested, Telcordia GR‑1435 compliant, and supports push‑pull latches for easy deployment.
Key features
- One MPO-12/APC (8 fibers active) splits into two separate MPO-12/APC connectors each carrying 4 fibers (2x200G or 400G per branch).
- Supports InfiniBand NDR, 800G/400G Ethernet, and NVLink; fully passive and transparent.
- APC finish reduces back reflections (return loss ≥35 dB) for superior signal quality.
- Crossed fiber mapping ensures correct TX/RX alignment between transceivers without external polarity adjustments.
- Low smoke zero halogen jacket rated for plenum/riser spaces (LSZH/OFNR), aqua color indicating OM3/OM4 multimode.
- Push-pull latching, dust caps pre-installed, 3.0 mm round cable diameter, 30 mm min bending radius.
- Built around 50/125μm multimode fiber (OM3 for ≤30m models, OM4 for >30m; MFP7E20-N015 utilizes OM4 for extended 15m performance with low insertion loss). The MPO-12/APC female connectors incorporate alignment holes that match transceiver pins, guaranteeing precise optical alignment. The “crossover" Type‑B interconnection ensures that lane 1 at the 4‑channel end (twin‑port OSFP side) maps to lane 12 at the first branch and lane 2 to lane 11 at the second branch, effectively enabling full-duplex communication. NVIDIA’s stringent insertion loss budget (≤0.35 dB + 0.0004 x L) ensures link reliability across temperature and humidity variations (-40°C to 85°C storage, 0-70°C operating).
Typical applications
- Connecting NVIDIA twin‑port OSFP 800G transceivers (e.g., MMA4Z00‑NS) in top‑of‑rack switches to ConnectX‑7 or BlueField‑3 DPU adapters using 400G OSFP/QSFP112 modules.
- High‑density server clustering where two servers share one switch port via 1:2 splitter configuration (each branch serves a separate compute node).
- AI/ML clusters requiring 200G per branch from a single 800G port, reducing cable bulk and optimizing airflow.
- Spine‑Leaf networks in data centers using multimode fiber for short‑reach, cost‑effective high‑speed interconnects up to 50 meters (with up to 2 patch panels).
