01Part-number led inquiry path
800G OSFP VR8 can be used as the direct starting point for quotation, BOM sharing and availability discussion.
Optical transceivers• 800G OSFP VR8
Advanced 800g Osfp Vr8 Transceiver for High-Performance Networks
800G OSFP VR8 multimode optical transceiver with 50m reach on OM4 fiber. Features dual MPO-12 APC connectors, CMIS 5.0 compliance, and supports 800G Ethernet and InfiniBand NDR applications.
RFQ
Inquiry ready
Clear path for part number, quantity and BOM-led contact.
EN / AR
Bilingual buyer flow
Useful for procurement teams coordinating technical review across regions.
Datasheet available
The product datasheet can be downloaded directly from this page.
Fast technical snapshotDatasheet available
800G OSFP VR8
Product photoCMS image ready
Selected specs
Deployment fit
Data-center Ethernet, HPC/InfiniBand NDR, Cloud/backbone & Metro, Access & Aggregation.
Follow-up path
Quote / Compatibility / Availability
Prepared for part-number led and BOM-led requests
800G OSFP VR8
Product photoCMS image ready
Product media
From product visual to RFQ context
When product photography is available it appears here for faster review, and a clean technical outline remains useful for early evaluation when imagery is limited.
01Product imagery when available
02Clear technical outline for fast review
03Built for specification review before inquiry
Overview
Product overview
Commercial 0–70 °C; 10G Offers Industrial –40–85 °C Option. High-speed: CMIS Rev 5.0+ With I²C; 10G: SFF-8472 DDM With I²C.
Key features
- Hot-pluggable OSFP form factor with dual MPO-12 APC connectors: Supports 800G VR8 and 8x100GbE breakout configurations
- Reach up to 30m on OM3 and 50m on OM4 multimode fiber: Compliant with CMIS Rev 5.0 for advanced management
- Low power consumption with maximum dissipation of 17W: Digital diagnostic monitoring via I2C interface
- This optical module adheres to OSFP MSA, IEEE P802.3db/D3.0, and IEEE P802.3ck standards. It utilizes PAM4 signaling at 53.125 GBaud per lane and integrates advanced diagnostics for real-time performance monitoring.
- The 800g osfp transceiver converts electrical signals into optical signals using VCSEL technology for transmission over multimode fiber. The receiver section employs PIN photodiodes for high-sensitivity detection. Internal CDR circuits ensure signal integrity and low jitter.
Typical applications
- Data-center Ethernet, HPC/InfiniBand NDR, Cloud/backbone & Metro, Access & Aggregation.
- 800G OSFP VR8 Optical Transceiver — CC-OSFP08VR8-12D: Experience high-speed data transmission with our 800g osfp transceiver, designed for 800 Gigabit Ethernet and InfiniBand NDR applications. This optical transceiver module delivers up to 50m reach on OM4 multimode fiber, featuring dual MPO-12 APC connectors, CMIS 5.0 management, and low power consumption. Ideal for data centers and high-performance computing environments.
- Hot-pluggable OSFP form factor with dual MPO-12 APC connectors: Supports 800G VR8 and 8x100GbE breakout configurations
- Reach up to 30m on OM3 and 50m on OM4 multimode fiber: Compliant with CMIS Rev 5.0 for advanced management
- Low power consumption with maximum dissipation of 17W: Digital diagnostic monitoring via I2C interface
- This optical module adheres to OSFP MSA, IEEE P802.3db/D3.0, and IEEE P802.3ck standards. It utilizes PAM4 signaling at 53.125 GBaud per lane and integrates advanced diagnostics for real-time performance monitoring.
Buying flow
How this product review turns into a real inquiry
This section gives buyers a practical handoff from technical review into quotation or compatibility follow-up.
01
Identify the exact target model
Start from 800G OSFP VR8 or the product name to reduce ambiguity before quotation starts.
02
Add quantity or deployment context
Share quantity, destination or BOM context so the commercial follow-up is aligned with the project scope.
03
Move into availability and fit review
Use the page as the handoff point for stock discussion, compatibility checks and delivery planning.
Technical snapshot
Trust signals
Why buyers use this page to review 800G OSFP VR8
The page is designed to reduce the distance between specification review and a real commercial inquiry.
Review
02Compatibility review before follow-up
The Advanced 800g Osfp Vr8 Transceiver for High-Performance Networks page is positioned to support compatibility questions and project-fit review before commercial action is finalized.
Project
03Project and quantity alignment
This model can be framed against use cases such as Data-center Ethernet, HPC/InfiniBand NDR, Cloud/backbone & Metro, Access & Aggregation. together with quantity and rollout timing.
Language
04English and Arabic follow-up
The bilingual route supports regional buying teams that need technical review and RFQ handling in two languages.
FAQ
Frequently asked questions about 800G OSFP VR8
Short answers that give buyers clearer expectations before they move into the quote form.
Can I request a quote for 800G OSFP VR8 directly from this page?01
Yes. This page is designed to move 800G OSFP VR8 review directly into quotation, availability or BOM discussion.
Does 800G OSFP VR8 support compatibility discussion before purchase?02
Yes. The page can be used to frame compatibility questions around Data-center Ethernet, HPC/InfiniBand NDR, Cloud/backbone & Metro, Access & Aggregation. before commercial follow-up.
Can 800G OSFP VR8 be compared with nearby models in the same family?03
Yes. Related products within the same category give buyers an internal comparison path before they submit an inquiry.
Can I send quantity or a BOM list with the inquiry?04
Yes. The inquiry path is designed to accept part numbers, quantity, BOM context and availability requirements in one submission.
