MMS4X00-NS400 can be used as the direct starting point for quotation, BOM sharing and availability discussion.
Optical transceivers• MMS4X00-NS400
NVIDIA MMS4X00-NS400 400G OSFP Transceiver DR4 Single-Mode for ConnectX-7 Adapters
400Gb/s OSFP transceiver with DR4 single-mode optics, 100m reach, dual InfiniBand/400GbE support, and auto-speed reduction to 200G with splitter cables.
RFQ
Inquiry ready
Clear path for part number, quantity and BOM-led contact.
EN / AR
Bilingual buyer flow
Useful for procurement teams coordinating technical review across regions.
Datasheet available
The product datasheet can be downloaded directly from this page.
Fast technical snapshotDatasheet available
MMS4X00-NS400
Product photoCMS image ready
Selected specs
400Gb/s (4x 100G-PAM4) or 200Gb/s (2x 100G-PAM4) auto-negotiated
1x MPO-12/APC (4 Tx + 4 Rx fibers)
CMIS 4.0, I²C, DDM, loopback, PRBS
NVIDIA ConnectX-7 OSFP adapters (400G and 200G modes)
Quantum-2 NDR InfiniBand switches (via twin-port MMS4X00-NS transceivers)
Spectrum-4 400GbE switches (via twin-port MMS4X00-NS transceivers)
Straight crossover fiber cables (MFP7E30-Nxxx, up to 100m)
1:2 splitter crossover fiber cables (MFP7E40-N0xx, up to 50m)
Deployment fit
25G / 100G / 400G / 800G optical links
Follow-up path
Quote / Compatibility / Availability
Prepared for part-number led and BOM-led requests
MMS4X00-NS400
Product photoCMS image ready
Product media
From product visual to RFQ context
When product photography is available it appears here for faster review, and a clean technical outline remains useful for early evaluation when imagery is limited.
01Product imagery when available
02Clear technical outline for fast review
03Built for specification review before inquiry
Overview
Product overview
The MMS4X00-NS400 is a single-port OSFP transceiver supporting both InfiniBand NDR and 400GbE protocols with auto-detection. Its flat-top housing mates with ConnectX-7 adapter riding heatsinks, utilizing a single MPO-12/APC optical connector with four transmit and four receive fibers powered by 1310nm EML lasers.
Key features
- 400Gb/s Data Rate: 4x 100G-PAM4 modulation, DR4 single-mode: Dual Protocol Support: InfiniBand NDR and 400Gb Ethernet auto-detection
- 100m Reach: Single-mode fiber with two patch panels assumed: Low Power Operation: 9W max (400G) / 5.5W max (200G) / 1.5W sleep
- Automatic Speed Reduction: Self-configures to 200Gb/s with 1:2 splitter cables
- Flat-Top OSFP Design: Riding heatsink compatibility for ConnectX-7: CMIS 4.0 Compliant: DDM, loopback, PRBS generator, field upgrade capability
- Class 1 Laser Safety: RoHS compliant, hot-pluggable, 0°C to +70°C operating range
Typical applications
- 25G / 100G / 400G / 800G optical links
- Switch-to-adapter interconnect
- Rack-to-rack optical deployment
Buying flow
How this product review turns into a real inquiry
This section gives buyers a practical handoff from technical review into quotation or compatibility follow-up.
01
Identify the exact target model
Start from MMS4X00-NS400 or the product name to reduce ambiguity before quotation starts.
02
Add quantity or deployment context
Share quantity, destination or BOM context so the commercial follow-up is aligned with the project scope.
03
Move into availability and fit review
Use the page as the handoff point for stock discussion, compatibility checks and delivery planning.
Technical snapshot
- 400Gb/s (4x 100G-PAM4) or 200Gb/s (2x 100G-PAM4) auto-negotiated
- 1x MPO-12/APC (4 Tx + 4 Rx fibers)
- CMIS 4.0, I²C, DDM, loopback, PRBS
- NVIDIA ConnectX-7 OSFP adapters (400G and 200G modes)
- Quantum-2 NDR InfiniBand switches (via twin-port MMS4X00-NS transceivers)
- Spectrum-4 400GbE switches (via twin-port MMS4X00-NS transceivers)
- Straight crossover fiber cables (MFP7E30-Nxxx, up to 100m)
- 1:2 splitter crossover fiber cables (MFP7E40-N0xx, up to 50m)
Trust signals
Why buyers use this page to review MMS4X00-NS400
The page is designed to reduce the distance between specification review and a real commercial inquiry.
Review
02Compatibility review before follow-up
The NVIDIA MMS4X00-NS400 400G OSFP Transceiver DR4 Single-Mode for ConnectX-7 Adapters page is positioned to support compatibility questions and project-fit review before commercial action is finalized.
Project
03Project and quantity alignment
This model can be framed against use cases such as 25G / 100G / 400G / 800G optical links together with quantity and rollout timing.
Language
04English and Arabic follow-up
The bilingual route supports regional buying teams that need technical review and RFQ handling in two languages.
FAQ
Frequently asked questions about MMS4X00-NS400
Short answers that give buyers clearer expectations before they move into the quote form.
Can I request a quote for MMS4X00-NS400 directly from this page?01
Yes. This page is designed to move MMS4X00-NS400 review directly into quotation, availability or BOM discussion.
Does MMS4X00-NS400 support compatibility discussion before purchase?02
Yes. The page can be used to frame compatibility questions around 25G / 100G / 400G / 800G optical links before commercial follow-up.
Can MMS4X00-NS400 be compared with nearby models in the same family?03
Yes. Related products within the same category give buyers an internal comparison path before they submit an inquiry.
Can I send quantity or a BOM list with the inquiry?04
Yes. The inquiry path is designed to accept part numbers, quantity, BOM context and availability requirements in one submission.
