MSB7890-ES2F can be used as the direct starting point for quotation, BOM sharing and availability discussion.
InfiniBand switches• MSB7890-ES2F
NVIDIA Mellanox MSB7890-ES2F 100G InfiniBand Switch 36-Port 7.2Tb/s Unmanaged Switch with P2C Airflow UFM Ready
High-performance 36-port 100G InfiniBand switch with 7.2Tb/s throughput, ultra-low latency, and UFM-ready for HPC/AI data centers. Features SHARP acceleration.
RFQ
Inquiry ready
Clear path for part number, quantity and BOM-led contact.
EN / AR
Bilingual buyer flow
Useful for procurement teams coordinating technical review across regions.
Datasheet available
The product datasheet can be downloaded directly from this page.
Fast technical snapshotDatasheet available
MSB7890-ES2F
Product photoCMS image ready
Selected specs
Deployment fit
Large‑Scale AI & ML Clusters – GPU‑based systems requiring centralized fabric management and telemetry across hundreds or thousands of nodes with UFM orchestration.
Follow-up path
Quote / Compatibility / Availability
Prepared for part-number led and BOM-led requests
MSB7890-ES2F
Product photoCMS image ready
Product media
From product visual to RFQ context
When product photography is available it appears here for faster review, and a clean technical outline remains useful for early evaluation when imagery is limited.
01Product imagery when available
02Clear technical outline for fast review
03Built for specification review before inquiry
Overview
Product overview
The NVIDIA Mellanox MSB7890‑ES2F is an unmanaged 100Gb/s InfiniBand smart switch designed for large‑scale data center deployments requiring centralized fabric management. Part of the NVIDIA SB7800 series, this switch delivers 36 QSFP28 ports operating at 100Gb/s per port, with an aggregate non‑blocking throughput of 7.2 Tb/s and ultra‑low port latency. Unlike its managed counterpart (MSB7800), the MSB7890‑ES2F is optimized for external management via NVIDIA Unified Fabric Manager (UFM), enabling data center operators to efficiently provision, monitor, troubleshoot, and maintain modern data center fabrics at scale. The MSB7890‑ES2F features the same high‑performance hardware as the managed SB7800 series, including an onboard dual‑core x86 CPU for switch hardware management (firmware, power supplies, fans) while relying on external Subnet Managers for fabric orchestration. With support for NVIDIA SHARP in‑network computing technology, the switch offloads collective operations from CPUs to the network fabric, dramatically accelerating MPI and deep learning workloads. The MSB7890‑ES2F variant features P2C (port‑to‑power) airflow, making it suitable for data center cooling architectures where cold air is supplied from the port side. Management Note: MSB7890-ES2F is an unmanaged switch variant optimized for external management. While it includes onboard hardware for basic chassis monitoring, fabric management (Subnet Manager) must be provided externally via NVIDIA UFM, OpenSM, or other standards‑compliant InfiniBand Subnet Managers.
Key features
- 100Gb/s InfiniBand per port – 36 QSFP28 ports delivering full bidirectional bandwidth with non‑blocking architecture.
- 7.2 Tb/s Aggregate Throughput – High‑density switching capacity in a compact 1U form factor.
- Unmanaged SKU for External Control – Optimized for centralized management via NVIDIA UFM platform; ideal for large‑scale fabrics requiring unified orchestration.
- In‑Network Computing Acceleration – NVIDIA SHARP technology offloads collective operations from CPUs to the switch fabric, reducing MPI operation time and freeing valuable CPU resources.
- UFM Ready – Seamless integration with NVIDIA Unified Fabric Manager for advanced telemetry, predictive analytics, and automated fabric orchestration across hundreds or thousands of switches.
- Redundant & Hot‑Swappable Components – 1+1 redundant power supplies with 80 Plus Gold certification, plus hot‑swappable fan modules for maximum availability.
- Energy Efficient Design – ATIS weighted power consumption as low as 122W for a fully populated system; dynamic power scaling reduces consumption when ports are not fully utilized.
- Flexible Cooling Options – P2C (port‑to‑power) airflow configuration (MSB7890-ES2F) with front‑to‑rear cooling.
Typical applications
- Large‑Scale AI & ML Clusters – GPU‑based systems requiring centralized fabric management and telemetry across hundreds or thousands of nodes with UFM orchestration.
- Hyperscale Data Centers – Fat‑tree, DragonFly+, and multi‑dimensional torus topologies managed through UFM for maximum efficiency and unified control.
- High‑Performance Computing (HPC) – Research labs, national labs, and universities where external fabric managers provide enhanced monitoring and automation capabilities.
- Enterprise & Cloud Service Providers – Environments requiring unified control plane across multiple switch fabrics with advanced telemetry and predictive analytics.
- Top‑of‑Rack (ToR) with Centralized Management – High‑density 100Gb/s leaf connectivity with fabric‑wide visibility and automated provisioning.
Buying flow
How this product review turns into a real inquiry
This section gives buyers a practical handoff from technical review into quotation or compatibility follow-up.
01
Identify the exact target model
Start from MSB7890-ES2F or the product name to reduce ambiguity before quotation starts.
02
Add quantity or deployment context
Share quantity, destination or BOM context so the commercial follow-up is aligned with the project scope.
03
Move into availability and fit review
Use the page as the handoff point for stock discussion, compatibility checks and delivery planning.
Technical snapshot
Trust signals
Why buyers use this page to review MSB7890-ES2F
The page is designed to reduce the distance between specification review and a real commercial inquiry.
Review
02Compatibility review before follow-up
The NVIDIA Mellanox MSB7890-ES2F 100G InfiniBand Switch 36-Port 7.2Tb/s Unmanaged Switch with P2C Airflow UFM Ready page is positioned to support compatibility questions and project-fit review before commercial action is finalized.
Project
03Project and quantity alignment
This model can be framed against use cases such as Large‑Scale AI & ML Clusters – GPU‑based systems requiring centralized fabric management and telemetry across hundreds or thousands of nodes with UFM orchestration. together with quantity and rollout timing.
Language
04English and Arabic follow-up
The bilingual route supports regional buying teams that need technical review and RFQ handling in two languages.
FAQ
Frequently asked questions about MSB7890-ES2F
Short answers that give buyers clearer expectations before they move into the quote form.
Can I request a quote for MSB7890-ES2F directly from this page?01
Yes. This page is designed to move MSB7890-ES2F review directly into quotation, availability or BOM discussion.
Does MSB7890-ES2F support compatibility discussion before purchase?02
Yes. The page can be used to frame compatibility questions around Large‑Scale AI & ML Clusters – GPU‑based systems requiring centralized fabric management and telemetry across hundreds or thousands of nodes with UFM orchestration. before commercial follow-up.
Can MSB7890-ES2F be compared with nearby models in the same family?03
Yes. Related products within the same category give buyers an internal comparison path before they submit an inquiry.
Can I send quantity or a BOM list with the inquiry?04
Yes. The inquiry path is designed to accept part numbers, quantity, BOM context and availability requirements in one submission.
